Technical Parameters: Model DFM1630/CDDW1630 DFM1630 (STANDARD) Parameter FULLY ELECTRIC FULLY ELECTRIC Drive system Battery Battery Driving mode Walkie Walkie Load Capacity Q KG 1600 1600 Load Center C MM 500 500 Weight (With battery) KG 515 515 Material PU PU Lifting Height H3 MM 3000 3000 Lowest Mast H1 MM 2080 2080 Max. Height when

Technical Parameters:

Features: With segment bending blade for the bending of box section. Various widths segment shiftable setup. With balanced hammer, it can easy to operate and easy for folding Technical Parameters: Model Capacity (mm) Packing size(cm) N.W./G.W.(kg) Length Thickness Angle DW2.5X1220 1220mm (48″) 2.5mm(12Ga) 0-135° 171x75x94 513 / 575 DW2.0X2040A 2040mm (80″) 2.0mm(14Ga) 0-135° 255x76x100 850 / 1000

Features: They have the function of air spring which can be installed inside the arm (optional) Our precision folding machine is used for bending the sheet metal parts. The upper blade can be dismantled for use. It can choose a combination of upper blades according to the abnormity degree and length of the workpiece. Technical Parameters: Model

Technical Parameters: Model D11-3×1250 D11-3×2050 D11-4×1300 D11-2×2550 Max.shearing thickness(mm) 3.0 3.0 4.0 2.0 Max.shearing width(mm) 1250 2050 1300 2550 Shearing angle 2° 2° 2.4° 1.6° No. of stroke (per minute) 30 30 30 30 Motor power(kW) 3 4 4 4 Back gauge(mm) 630 630 630 630 Dimension(cm) 184*103*135 266*116*147 191*116×145 320x116x148 N.W.G.W. 960/1140 1520/1650 1320/1520

VERTICAL MACHINE CENTER / CNC MILLING MACHINE DVMC550 / DVMC640 DVMC650 / DVMC840 Standard Configuration: System: KND-1000/GSK980MDi 16 Armless Tool Magazine 3 axis Linear Rail Technical Parameters SPECIFICATIONS Units DVMC550 DVMC640 DVMC650 DVMC840 Table size mm 700*350 800*300 800*400 1000*400 X axis travel mm 550 600 650 800 Y axis travel mm 350 360 400

Technical Parameters Drilling Machine Specifications and Ordering Information MODEL MAX. DRILLING CAPACITY MAX. ANNULAR CUTTING CAPACITY MAX. TAPPING CAPACITY RATED INPUT POWER MAGNETIC ADHESION NO-LOAD SPEED SOFT START PROTECTION OVERLOAD SPEED CONTROL STEPLESS REVERSIBLE REVERSIBLE Tool Holder BJ-2800E ○ 28mm ○ 1480 W 13000 N 0-680 RPM ● ● ○ ○ Weldon Shank 3/4″ BJ-3800E
