Features:
- The UG (finite element) analysis method was used to optimize the design with computer aid. The fuselage adopts integral steel plate welded structure, which has good strength, rigidity and vibration resistance.
- Internal stress relief by tempering.
- The whole frame is sanded to remove rust and sprayed with anti-rust paint. The table is equipped with an auxiliary tool holder for easy blade adjustment.
- The work surface is equipped with feeding balls, which is light to operate.
- The blade gap adjustment adopts stepless adjustment mechanism to adapt to the shearing needsof different plate thicknesses and materials.
- Rectangular lower blade with four cutting edges for extended blade life. Adjust the shear stroke to improve processing efficiency and realize segmented shearing function.
- The number of cuts is automatically counted, which reduces the inventory work of cumbersome locks
| Model | Thickness (mm) |
Width (mm) |
Cutting Angle (°) |
Material Strength (Kj/cm) |
Backgear Travel (mm) |
Cutting Times (T/min) |
Power (kW) |
Weight (T) |
Overall Dimension L×W×H (mm) |
|---|---|---|---|---|---|---|---|---|---|
| 4×2500 | 4 | 2500 | 1°30′ | ≤450 | 20–600 | 16 | 5.5 | 3.4 | 3100×1700×1650 |
| 4×3200 | 4 | 3200 | 1°30′ | ≤450 | 20–600 | 14 | 5.5 | 4.1 | 3800×1700×1650 |
| 4×4000 | 4 | 4000 | 1°30′ | ≤450 | 20–600 | 10 | 5.5 | 5.6 | 4600×1750×1750 |
| 6×2500 | 6 | 2500 | 1°30′ | ≤450 | 20–600 | 14 | 7.5 | 4.4 | 3100×1750×1700 |
| 6×3200 | 6 | 3200 | 1°30′ | ≤450 | 20–600 | 12 | 7.5 | 5.1 | 3800×1750×1700 |
| 6×4000 | 6 | 4000 | 1°30′ | ≤450 | 20–600 | 8 | 7.5 | 7.6 | 4600×1850×1850 |
| 6×5000 | 6 | 5000 | 1°30′ | ≤450 | 20–600 | 6 | 11 | 12.5 | 5600×2050×2180 |
| 6×6000 | 6 | 6000 | 1°30′ | ≤450 | 20–600 | 5 | 11 | 14.8 | 6600×2120×2230 |
| 8×2500 | 8 | 2500 | 1°30′ | ≤450 | 20–600 | 10 | 11 | 5.3 | 3100×1750×1700 |
| 8×3200 | 8 | 3200 | 1°30′ | ≤450 | 20–600 | 8 | 11 | 6.5 | 3800×1750×1700 |
| 8×4000 | 8 | 4000 | 1°30′ | ≤450 | 20–600 | 8 | 11 | 7.7 | 4600×1850×1850 |
| 8×5000 | 8 | 5000 | 1°30′ | ≤450 | 20–600 | 8 | 11 | 13.5 | 5600×2120×2120 |
| 8×6000 | 8 | 6000 | 1°30′ | ≤450 | 20–600 | 8 | 11 | 15.8 | 6600×2200×2280 |
| 10×2500 | 10 | 2500 | 2° | ≤450 | 20–600 | 9 | 11 | 6.5 | 3100×1820×1920 |
| 10×3200 | 10 | 3200 | 2° | ≤450 | 20–600 | 9 | 11 | 7.7 | 3800×1820×1920 |
| 10×4000 | 10 | 4000 | 2° | ≤450 | 20–600 | 8 | 11 | 9.1 | 4600×1900×2000 |
| 10×6000 | 10 | 6000 | 2° | ≤450 | 20–600 | 8 | 15 | 22 | 6600×2400×2350 |
| 12×2500 | 12 | 2500 | 2° | ≤450 | 20–600 | 9 | 18.5 | 9 | 3100×1820×1920 |
| 12×3200 | 12 | 3200 | 2° | ≤450 | 20–600 | 9 | 18.5 | 9.4 | 3800×1820×1920 |
| 12×4000 | 12 | 4000 | 2° | ≤450 | 20–600 | 8 | 18.5 | 11.8 | 4600×1950×2100 |
| 12×5000 | 12 | 5000 | 2° | ≤450 | 20–750 | 8 | 18.5 | 15.8 | 5600×2400×2350 |
| 12×6000 | 12 | 6000 | 2° | ≤450 | 20–750 | 8 | 18.5 | 26 | 6600×2400×2350 |
| 16×2500 | 16 | 2500 | 2°30′ | ≤450 | 20–600 | 9 | 22 | 9.2 | 3100×1950×2060 |
| 16×3200 | 16 | 3200 | 2°30′ | ≤450 | 20–600 | 8 | 22 | 10.8 | 3800×1950×2080 |
| 16×4000 | 16 | 4000 | 2°30′ | ≤450 | 20–600 | 8 | 22 | 15.3 | 4600×2300×2180 |
